High Rigidity Fixed Beam Single Head CNC Gantry Grinding Machine, 2000×800mm Worktable, Flatness 0.005mm/1000mm, Heavy Load 5000kg
1. Product Overview
If you are looking for a heavy-duty, long-service-life, ultra-precision gantry surface grinder for large mold bases, steel plates, casting frames, mechanical structural parts, our Fixed Beam Single-Head Gantry Grinding Machine is your ideal manufacturing partner.
This CNC gantry grinder adopts fixed triangular beam closed frame structure, specially designed for heavy load & large-size workpiece flat grinding. Equipped with Yonghong PLC+HMI two-axis servo control system, it realizes stable automatic grinding with micron-level precision, widely adopted in mold manufacturing, automotive parts, heavy machinery, aerospace, steel processing industries worldwide.
2. Core Competitive Advantages (7 Unique Strengths)
1 High-Rigidity Triangular Crossbeam Structure
Triangular integrated beam greatly boosts bending & torsion resistance. The grinding head is tightly locked on beam without vibration during grinding. No wheel jumping or rapid dulling, effectively lift grinding efficiency and long-term precision stability, solving the precision drifting problem of ordinary gantry grinders under heavy cutting.
2 Taiwan Imported PTFE Laminated Guideways + Full Dustproof Cover
All guide rails go through precision grinding + manual scraping process, covered with Taiwan Teflon soft strips. Low friction coefficient, energy saving, smoother running and lower power consumption. Full-enclosed dust shield fully isolates grinding dust & coolant from guide rails, avoid corrosion and abrasion, extend machine service life by 30%+.
3 Precision Ball Screw Transmission with Self-Locking
X/Y/Z three axes use high-precision ball screw + refined gearbox transmission, featuring high transmission efficiency, accurate positioning and self-locking function. Supporting electronic handwheel for manual fine feeding; Z-axis minimum feed reaches 0.005mm, easy for ultra-fine finishing.
4 Ultra-Precision Custom Spindle Assembly
Flange spindle adopts ultra-precision angular contact ball bearings for outstanding grinding rigidity. Spindle & motor are customized by Taiwan professional factory, Japan imported coupling. After strict dynamic balance calibration, vibration level reaches V3 standard, spindle runout controlled within 0.003mm, guarantee mirror-level grinding finish.
5 Intelligent Intermittent Circulating Lubrication System
Independent circulating oil supply for beam & vertical guideways, automatic timed oiling. Realize full-range sufficient lubrication without oil waste or workpiece oil pollution, protect guide rails & screws to maintain consistent long-term accuracy.
6 Simple Humanized CNC Operation Panel
Integrated Yonghong PLC touchscreen control, common grinding functions set as shortcut buttons, no complicated professional programming required. Novice operators can master operation within 1 hour. Matched with electronic handwheel for quick alignment & fine adjustment, lower labor training cost for your factory.
7 Heavy-Duty Heat-Treated Machine Body
Bed base, crossbeam and sliding blocks adopt high-frequency quenching treatment for high hardness and wear resistance. Worktable & cross slide lined with PTFE material, support max 5000kg heavy workpiece loading without deformation.
3. Key Technical Parameters
| Specification | Standard Value |
|---|---|
| Worktable Working Area | 2000mm × 800mm |
| Max Grinding Length (X-axis travel) | 2200mm |
| Gantry Column Inner Width | 1000mm |
| Y-axis Horizontal Spindle Travel | 870mm |
| Max Grinding Height | 320mm |
| Max Distance Table Surface to Spindle Center | 850mm |
| Z-axis Minimum Fine Feed | 0.005mm |
| Horizontal Grinding Head Power | 20HP |
| Grinding Wheel Size | 500×203×50~75mm |
| Grinding Wheel Rotation Speed | 1450RPM |
| Max Worktable Load | 5000kg |
| Worktable Moving Speed | 5~30m/min |
| Flatness Accuracy | 0.005mm / 1000mm |
| Spindle Runout Tolerance | ≤0.003mm |
| Power Supply | 380V Three-Phase |
| Overall Machine Height | Approx. 3200mm |
| Floor Space (L×W) | 6350mm × 3000mm |
| Total Machine Weight | Approx. 12000kg |
4. Complete Standard Configuration (One-Stop Delivery, Save Your Extra Purchasing Cost)
5. Wide Application Scenarios
- Large plastic mold, die casting mold base flat grinding
- Heavy steel plate, cast iron frame surface finishing
- Machine tool base, guide rail precision processing
- Automotive large structural parts, hydraulic manifold blocks
- Aerospace alloy large-size plane grinding
- General machinery heavy-duty component planar finishing
6. Why Choose Us As Your Gantry Grinder Supplier?
1. Factory Direct Price: No middleman markup, competitive factory ex-work price for bulk orders; support trial order for new clients.
2. Stable Imported Core Parts: Taiwan spindle/motor, Japan coupling, Taiwan PTFE soft strips, stable performance, low failure rate.
3. Strict Pre-Delivery Inspection: Each machine goes through 72-hour continuous running test, flatness & spindle precision full detection before shipment; provide machine test video for your confirmation.
4. Global After-Sales Support: 1-year warranty for whole machine, lifetime technical consultation; supply spare parts with fast delivery, remote video troubleshooting guide.
5. Customization Available: We can adjust worktable size, spindle power, add automatic dressing system or vacuum chuck per your processing demands.
6. Complete Export Documents: Support CE certification, factory inspection report, commercial invoice, packing list for smooth customs clearance in Europe, Southeast Asia, Middle East, America.
