Fagor linear scale dro linear scale measurement linear encoder

Short Description:

Product Detail

Product Tags

General Characteristics
Measurement By means of a 20 um-pitch
(0.0008 inch)graduated glass.
Glass thermal expansion coefficient 8 ppm/K
Accuracy ±5 um (±0.0002")
±3 um (±0.00012")
Maximum speed 120m/min
Maximum vibration 20g
Moving thrust <5N
Operating temperature 0°...50℃
Storage temperature `-20°...70℃
Weight 0.25KG+2.25KG/M
Relative humidity 20...70℃
Protection IP 53(Standard)
IP 64(DIN 40050)using pressurized
