PCA2550 Precision surface grinding machine

Short Description:

  • Table Size(x*y): 250×500mm
  • X axis travel: 600mm
  • Y axis travel: 280mm
  • Max center of wheel to table: 480mm
  • Maximum load: 250kg
  • Model: AHR / AHD / NC / CNC
  • Product Detail

    Product Tags

    About product quality control, with the inspection of advanced equipment from the United States(API) and Japan(NIKON), the quality are well guaranteed. We also trade CNC Milling Machine, surface grinder and other machines with good quality.

    The Main feature

     Entire welded frame, tempering

     Steel plate welded structure is adopted, with hydraulic transmission and accumulator return, typical of an easy operation, reliable performance, and nice appearance, fitted with digital display system.

     Indication by indicator is provided for adjustment fo blade clearance for a handy and prompt adjustment.

     Alignment device with lighting and control device for shearing stroke are ste, with a handy and rompt adjustment.

     Rolling material support bal is provide, to minimize fish tail with sheet bar andto reduce  frictional resistance.

    Technical parameter of Hydraulic shearing machine 6x3200MM with E21

    Hydraulic System

     Hydraulic system is from Bosch -Rexroth, Germany.

     Adopt integrated hydraulic control system, more reliable and easy for maintenance.

     Hydraulic transmission with high reliability, integrated hydraulic system can effectively alleviate problems caused by leakage of hydraulic fluid.

     Overload overflow protection is outfitted to hydraulic system, which can assure no leakage, and the oil level can be read or seen directly.

    The hydraulic system is made in compliance with current r.

    Controller E21S

     monochrome LCD Box Panel.

     Integral factor programmable freely

     Automatic positioning control

     Spindle allowance offset

     Internal time relay and Stock counter

     Backgauge position display, resolution in 0.05mm

    Controller E21S

    The main technical

    Parameters Table parameter Unit PCA-250
    Capacity Table Size(x*y) mm 200×500
    X axis travel mm 600
    Y axis travel mm 280
    Max center of wheel to table mm 480
    Maximum load kg 250
    Table X axis Table T cell specification mm×N 14×1
    Table speed m/min 5-25
    Y axis hand wheel feed degree scale mm 0.02/5
    automatic feed mm 0.1-8
    Fast moving speed mm/min 990/1190
    Grinding wheel grinding wheel size max mm Φ180×12.5×31.75
    grinding wheel speed R.P.M 2850/3360
    Z axis hand wheel feed degree scale mm 0.005/1
    Fast moving speed mm/min -
    Motor spindle motor HxP 2x2
    theZ axis motor W -
    hydraulic motor H×P 1.5×6
    cooling motor W 40
    the Y axis motor W 80
    Size Machine Tool Profile Size mm 1750x1400x1680
    weight kg ≈1350

    The detail

    The detail1
    The detail2
    The detail3
    The detail4
